Manufacturer: Cessna
Aircraft Model(s): 206, U206, U206(A-G), P206, P206(A-E)
Applicable Engines: IO-520-(A,F)-CF, IO-550-F, IO-550-F-CF, IO-550-N
PDF: 206, U206(A-G), P206(A-E)
Advantages:
- Increased takeoff and climb performance
- Lightest 3 blade available
- Unlimited Life Blades
- Top Prop Warranty to first overhaul
Landplane / Floatplane
Order Part #C3F20170STP Kit (80″ Diameter) includes:
- Vitatoe Aviation…………………………………………………….206, U206, U206(A-G), P206(A-E)…………………………………………………………..IO-520-(A,F)-CF
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | HC-C3YF-1N/NM8411-6/SM30 |
| 1 | Polished Spinner | A-2295-1P |
| 1 | STC Document Set | SA04643CH |
Landplane / Floatplane
Order Part #C3F20164STP Kit (82″ Diameter) Includes:
- Summit Aviation……………………………………………………………U206(B-G), P206(A-E)…………………………………………………………………………………….IO-550-N
- Wipaire………………………………………………………………………………………….U206(E-G)……………………………………………………………………………………………..IO-550-F
- Vitatoe Aviation……………………………………………………206, U206, U206(A-G), P206(A-E)………………………………………………………………….IO-550-F-CF
- Summit Aviation…………………………………………………………………..U206(B-G)……………………………………………………………………………………………………IO-550-F
- Davis Aviation……………………………………………………..206, U206, U206(A-G), P206, P206(A-E)……………………………………………………………IO-550-F
- Texas Skyways……………………………………………………….206, U206, U206(A-G), P206, P206(A-E)……………………………………………………………IO-550-F
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | HC-C3YF-1N/NM8411-4/SM30 |
| 1 | Polished Spinner | A-2295-1P |
| 1 | STC Document Set | SA04643CH |
Floatplane
Order Part #C3F20167STP Kit (86″ Diameter) Includes:
- Texas Skyways……………………………………………………206, U206, U206(A-G), P206, P206(A-E)…………………………………………………………………IO-550-F
- Davis Aviation………………………………………………………206, U206, U206(A-G), P206, P206(A-E)…………………………………………………………………IO-550-F
- Vitatoe Aviation……………………………………………………..206, U206, U206(A-E), P206(A-E)…………………………………………………………………….IO-550-F-CF
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | HC-C3YF-1N/NM8411/SM30 |
| 1 | Polished Spinner | A-2295-1P |
| 1 | STC Document Set | SA04643CH |
Applicable Models: 206, U206, U206(A-G), P206, P206(A-E)
Specifications:
- Applicable engines: IO-520-(A,F)-CF, IO-550-F, IO-550-F-CF, IO-550-N
- 80, 82, or 86 inch diameter 3-bladed aluminum hub carbon fiber propeller
- 2400 hour / 6 year TBO
- 80″: 62.6 pounds (C-Hub propeller and A-2295-1P spinner)
- 82″: 62.8 pounds (C-Hub propeller and A-2295-1P spinner)
- 86″: 63.1 pounds (C-Hub propeller and A-2295-1P spinner)
- NO RPM RESTRICTIONS
